Basic Dimensions
Diameter (mm) | Kerf | Bore | Tooth Number | Tooth Configuration |
| 200 | 3.2 | 30 | 36 | TCG or TT or ATB or Flat |
| 250-315 | 3.2 | 30 | 60 | TCG or TT or ATB or Flat |
| 300-315 | 3.2 | 30 | 96 | TCG or TT or ATB or Flat |
| 350 | 3.5 | 30 | 96 | TCG or TT or ATB or Flat |
| 350-400 | 4.4 | 30-80 | 48 | TCG or TT or ATB or Flat |
| 350-400 | 4.4 | 30-80 | 96 | TCG or TT or ATB or Flat |
Features
- Made from 100% virgin raw material.
- Good toughness, superior wear resistance and high strength.
- Excellent performance and good wear corrosion resistance.
- HIP sintering, good compactness.
- High machining accuracy.
- Sharp edge and smooth surface.
- Strict products quality inspection.
- Used for steel, stainless steel, cast steel and cast iron cutting and processing.
- Stable quality and high efficiency.
Performance of Common Used Grades
| Grade | Производительность | ||
| Density (g/cm3) | Bend Strength | Hardness (HRA) | |
| YG3 | 14.9-15.3 | ≥1180 | ≥90.5 |
| YG3X | 15.1-15.4 | ≥1300 | ≥91.5 |
| YG6X | 14.8-15.1 | ≥1560 | ≥91.0 |
| YG6A | 14.7-15.1 | ≥1580 | ≥91.0 |
| YG6 | 14.7-15.1 | ≥1670 | ≥89.5 |
| YG8 | 14.6-14.9 | ≥1840 | ≥89.0 |
| YT15 | 11.1-11.6 | ≥1180 | ≥91.0 |
| YT14 | 11.2-11.8 | ≥1270 | ≥90.5 |
| YT5 | 12.5-13.2 | ≥1430 | ≥89.5 |
| YW1 | 12.7-13.5 | ≥1180 | ≥91.5 |
| YW2 | 12.5-13.2 | ≥1350 | ≥90.5 |
Our Advantages
- Excellent wear resistance improves the blade life.
- Use low-temperature treatment technology to improve the internal micro-structure to avoid cracking.
- High precision, no glitches, and nice abrasion resistance.
- We use HIP sintered, fine grinding and polishing plating to reduce frictions when cutting, improved the accuracy and speed slitting greatly.
- Specialize in cutting all kinds of aluminum, metal and etc. Different grades are available.
