Product Features
- Efficient cutting: Designed for fast cutting, it can remove a large amount of material in a short time.
- Durability: Made of high quality cemented carbide, precision machined and specially coated for excellent wear resistance and long life.
- Multiple edge types: Optimized cutter body design and multiple edge design to adapt to different cutting needs and material characteristics.
- Wide applicability: Suitable for roughing steel, cast iron, stainless steel, alloy and other materials with high efficiency metal removal rate.
- Customized service: We provide OEM, ODM, OBM and other customized services, we can customize roughing milling cutters with different specifications, materials and coatings according to customers’ needs. The MOQ depends on the specific customization requirements, welcome to inquire.
Specification
| Material | Cemented carbide
(optional HSS M42) |
| Coating | TICN coating, TIN coating, TIALN superhard nano-coating
(available depending on the specific application) |
| Diameter | Various sizes available, such as 4mm, 6mm, etc. |
| Number of Blades | Typically features a higher number of edges to improve cutting efficiency |
| Helix Angle | Optimized helix angle design to reduce cutting forces and vibration |
| Hardness | HRA 92.6 |
| Machining Hardness | Suitable for materials up to HRC50 |
| Edge Treatment | Special edge treatment technology to improve cutting performance and chip removal efficiency |
Applications
- Mold machining: For rough machining of mold cavities and cores.
- Machining: Suitable for rough milling of mechanical parts, such as cases and covers.
- Aerospace: Used for rough machining of aircraft parts and engine components.
