Product Features
- High hardness: Made of high hardness cemented carbide material, it can easily cope with various hardness of rocks and strata.
- Resistência ao desgaste: Due to its good wear resistance, the tungsten carbide button has a long service life, which reduces the replacement frequency and cost.
- Various shapes: Tungsten carbide button can be customized into spherical, conical, wedge, spoon, flat-top, parabolic and other shapes according to the specific needs to meet the needs of use in different working conditions.
- High precision: Advanced production process and technology are adopted to ensure the dimensional precision and surface quality of tungsten carbide button.
Product Specification
|
Spherical |
Parabolic | ||||
| Diameter | Height | Radius | Diameter | Height |
Crest Height |
|
8.2 |
12.0 | 4.2 | 7.2 | 11.0 | 3.9 |
| 9.2 | 13.0 | 4.6 | 8.2 | 12.0 |
4.3 |
|
10.2 |
14.0 | 5.2 | 9.2 | 13.0 | 5.0 |
| 11.2 | 15.0 | 6.0 | 10.2 | 15.0 |
5.2 |
|
12.2 |
17.0 | 6.6 | 11.2 | 16.0 | 5.8 |
| 13.2 | 19.0 | 6.7 | 12.3 | 17.0 |
6.7 |
|
14.3 |
22.0 | 7.2 | 13.3 | 18.0 | 6.8 |
| 16.3 | 24.0 | 8.8 | 14.3 | 20.0 |
7.3 |
|
18.3 |
27.0 | 9.2 | 16.3 | 24.0 | 8.4 |
| 19.2 | 25.0 | 9.6 | 18.3 | 27.0 |
10.5 |
Support customization
Applications
Tungsten carbide button is widely used in the following fields:
- Mining: used for mining and crushing various rocks.
- Quarrying: for cutting and breaking rocks in quarries.
- Tunneling: used to break rocks and dig in the tunnel excavation process.
- Civil construction: used for drilling and crushing operations in infrastructure construction (e.g. roads, bridges, buildings, etc.).
